Part Number: AXAMP-FD3
Details
This vehicle-specific 6-channel amplifier integration interface from Axxess enables the installation of aftermarket amplifiers for enhanced sound quality while retaining the vehicle's original radio and features. This interface includes an external bass knob for additional audio output level adjustments.
Features:
- Designed for amplified and non-amplified systems
- Provides 6 channels of 5-volt RMS audio
- Non-fading full-range output (channels 5 and 6)
- Simple plug-n-play installation behind the radio
- No programming required
- Dual-colored LED feedback light
- Input: 50W per channel
- Amp turn-on trigger (DC): 250mA
- 2-channel S/PDIF out (front)
- 1-year warranty
Includes:
- AXAMP-FD3 Amplifier integration interface
- Bass knob
- Extension harness
- Resistor pad
- Instruction sheet
Applications
- FORD
- Bronco Sport 2020-2023 , Passenger Side Trunk Behind Seat.
- EcoSport 2018-2023 , , Passenger Side Trunk Behind Seat.
- Escape 2020-2023 , Driver Side Trunk Behind Rear Seat.
- E series 2021-2023 , N/A
- Expedition 2022-2024 , Non-amplified , N/A
- Explorer 2020-2023 , Left Rear Quarter Panel
- F-150 2021-2022 , Driver Side Rear Floor, Behind Rear Seat.
- F-250 2020-2020 , non-amplified , N/A
- Ranger 2024-2025 , non-amplified , N/A
